🔒 Setting Up Remote Access to OpenWebUI Without VPN

Welcome! In this guide, I’ll show you how to access an internal web service from anywhere without VPN.

The Challenge

I had an OpenWebUI service running on our internal server that I could only access through VPN. Every time I needed to use it, I had to:

1. Start GlobalProtect VPN service
2. Run an SSH tunnel command to forward ports
3. Access through localhost

This was cumbersome. I wanted a simpler solution that would:

• Work from anywhere without VPN
• Be persistent and auto-restart
• Use proper authentication
• Start automatically after server reboots

Environment Setup

Here’s what we’re working with:

• OpenWebUI service on internal server: <INTERNAL_IP>:3000
• Jump server accessible from internet: <JUMP_SERVER_IP>
• My username: <USERNAME>

Solution 1: Quick SSH Tunnel

Let’s start with the simplest solution. First, set up your SSH config:

# In ~/.ssh/config on your local machine
Host jump-server
   HostName <JUMP_SERVER_IP>
   User <USERNAME>
   Port <JUMP_SSH_PORT>

Host webui-server
   HostName <INTERNAL_IP>
   User <USERNAME>
   Port <INTERNAL_SSH_PORT>
   ProxyJump jump-server

Now you can create the tunnel with a single command:

ssh -L 30000:localhost:3000 -J jump-server webui-server -N &

This works! Access OpenWebUI at http://localhost:30000. But running this manually gets old fast.

Solution 2: Permanent System Service

Let’s make it permanent. On the jump server:

1. Create the tunnel service:

   sudo nano /etc/systemd/system/webui-tunnel.service


2. Add this configuration:

   [Unit]
   Description=Public SSH tunnel for OpenWebUI
   After=network.target

   [Service]
   ExecStart=/usr/bin/ssh -N -o GatewayPorts=yes -L *:30000:localhost:3000 <USERNAME>@<INTERNAL_IP> -p <INTERNAL_SSH_PORT>
   Restart=always
   RestartSec=60
   User=<USERNAME>
   Environment=AUTOSSH_GATETIME=0
   TimeoutStartSec=10min

   [Install]
   WantedBy=multi-user.target


3. Start and enable the service:

   sudo systemctl daemon-reload
   sudo systemctl start webui-tunnel
   sudo systemctl enable webui-tunnel


4. Verify it’s working:

   # Install netstat if needed
   sudo apt install net-tools

   # Check if tunnel is listening
   sudo netstat -tulpn | grep 30000


   You should see:

   tcp     0    0 0.0.0.0:30000    0.0.0.0:*    LISTEN    xxxxx/ssh
   tcp6    0    0 :::30000         :::*         LISTEN    xxxxx/ssh


Failed Experiment: Nginx Authentication

I tried adding Nginx as an authentication layer, but it didn’t play nice with OpenWebUI’s login system. Here’s what I tried:

1. Install Nginx:

   sudo apt update
   sudo apt install nginx apache2-utils


2. Create password file:

   sudo htpasswd -c /etc/nginx/.htpasswd <USERNAME>


3. Configure Nginx:

   sudo nano /etc/nginx/sites-available/webui


   With this config:

   server {
       listen 30001;
       server_name <JUMP_SERVER_IP>;

       location / {
           auth_basic "Restricted Access";
           auth_basic_user_file /etc/nginx/.htpasswd;

           proxy_pass http://localhost:30000;
           proxy_set_header Host $host;
           proxy_set_header X-Real-IP $remote_addr;
           proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
           proxy_set_header X-Forwarded-Proto $scheme;
       }
   }


   This caused authentication loops, so I removed it:

   sudo apt remove nginx nginx-common
   sudo apt autoremove


The Result

After all this work:

• OpenWebUI is accessible at http://<JUMP_SERVER_IP>:30000 from anywhere
• It uses its built-in authentication
• The tunnel auto-restarts if it fails
• Everything comes back after server reboots

Additional Notes

Some important details:

• No firewall configuration needed (UFW was inactive)
• Service runs under user account
• Internal server still needs proper SSH key setup
• Replace all <PLACEHOLDERS> with your actual values!

Future Improvements

Potential enhancements I’m considering:

• Adding HTTPS support
• Implementing rate limiting
• Setting up monitoring and alerts
• Adding IP-based access control

Need Help?

If you’re implementing this:

• Double-check all your IP addresses and ports
• Make sure SSH keys are set up correctly
• Test the tunnel before enabling the service
• Keep your original manual tunnel command handy as backup

License

Feel free to use and modify this setup as needed. Just remember to secure your services properly! 🔒
